Ganymede Insulated Roller Shutter Doors
The energy efficient shutter
Ganymede insulated roller shutter doors from Priory offer a viable alternative to the insulated sectional overhead door. They provide insulation whilst retaining the standard roller shutter drive system, which is easy to install and maintain.
Insulation made easy
The insulated roller shutter door coils up neatly above the opening, and does not encroach or cover the roof area behind the door, whereas a sectional over head door usually requires connection to the overhead roof structure.
Cost effective, FAST TO INSTALL
Installation is speedy due to the simple design of a roller shutter that also keeps maintenance costs low and any repairs to the door curtain, if required, are normally less expensive as the curtain is built up from individual lath that are straightforward to replace.
CURTAIN OPTIONS
STANDARD OR VISION OPTIONS
Insulated roller shutter doors are suitable for internal and external openings in a wide range of applications such as warehouses, industrial units, workshops, spray booths, bus depots etc.
Ganymede roller shutters are available with two types of lath:-
GANYMEDE Insuroll SOLID
Each individual lath is made up of two interlocking sections held together over their length by the interlocking quirk profile. Every section is 100 mm deep with a twin indented face and is built up together with nylon endlocks to form the complete curtain.
GANYMEDE Insuroll With Vision
Curtains are also available with glazing elements for vision and light.
CFC and HFCFC free polystyrene is inserted into each lath section to provide a “U” value of 0.69 w/m2k and an acoustic value of 18dBa.
GANYMEDE Insufoam lath
Insufoam is a foam filled lath and has a double skin profile roll-formed from a single steel section featuring a hot injection polyurethane central core. The infill bonds to the internal face of the section providing strength, rigidity and of course excellent thermal and acoustic values.
GANYMEDE Insufoam with vision
Our 75 mm deep lath has a “U” value of 2.4 w/m2k and a “R” value of 0.42 w/m2k and an acoustic value of 21dBa. Shown here with a mix of solid and vision laths.
COLOURS
Both the Ganymede Insuroll and the Ganymede Insufoam insulated roller shutter doors can be supplied in a standard galvanised steel finish or can be part or fully powder coated to almost any standard RAL or BS colour. Please check colour availability prior to quotation.
Galvanised
Standard finish
RAL or BS colours
Insuroll & Insufoam Powder coated
Insuroll Plastisol HPS200
On the Ganymede Insuroll, a popular option to finish one face of the curtain (usually the external face) in Plastisol HPS200 in the colours listed.
Insufoam Plastisol HPS200
On the Ganymede Insufoam, Plastisol HPS200 finishes are available colour coated to both faces of the curtain in the colours listed.
Plastisol HPS200 Colours
- White
- Black
- Goosewing Grey
- Merlin Grey
- Ocean blue
- Sargasso Blue
- Solent Blue
- Olive Green
- Heritage Green
- Moorland Green
- Juniper Green
- Van dyke Brown
- Mushroom
- Aztec Yellow
- Poppy Red
OPERATION
Tube Motors or Single/Three Phase Motors
The following types of motors can be supplied with Ganymede insulated roller shutter doors: –
- Single phase tube motors
- Single phase in-board mounted industrial motors
- Single phase out-board mounted direct drive motors
- 3 phase flange mounted chain and sprocket driven in-board and out-board motors
- 3 phase out-board mounted direct drive motors
Motors are available from all of the largest motor manufacturers in the world, Ellard, Link Controls and GfA – Please state your preference at time of enquiry.
Extensive Applications
Conserve energy with solutions for industry sectors that require thermally efficient buildings:
Ganymede Insulated Roller Shutter Doors example installations
Fully compliant doors
Each Ganymede Insulated roller shutter door has been fully tested to the CPR (Construction Products Regulation) EN13241-1:2003 + A1:2011 by a UKAS accredited testing laboratory and is supplied with a DoP (Declaration of Performance) which can be downloaded from the specification section.
MACHINERY DIRECTive
Each door is also fully compliant to the machinery directive 98 / 37 / EC. It has been mandatory for the installer of the door to “CE” mark the product to the machinery directive since January 1st 1995. For you (the installer) to satisfy the conditions of your own technical file, the Declaration of Incorporation can be found in the specification section or the downloads area.
Your Warranty
Ganymede is covered by warranties for the periods stated below, subject to terms and conditions (available on request and supplied with every door) and regular maintenance.
1 YEAR
Warranty on door components against manufacturing defect.
1 YEAR
Warranty on motor and controls excluding batteries, transmitters and bulbs.
Priory is totally committed to trade supply, support and service. Get in touch to enquire about a trade account now.
We only supply to trade however, if you like our products then get in touch and we’ll put you in touch with one of our trusted suppliers.
