Callisto Continental Roller Shutters Specification
Fixing options and shutter dimensions
An overview of Callisto Continental Roller Shutters Specification, including shutter fixing locations, key dimensions and sizing information. Not what you need? Contact the team…
Specification
Fixing Locations
Standard face fix
Mounting the shutter onto the face of an opening is the most typical method for built-on applications. The shutter is fitted above the opening, with the
guide channels to either side. A full canopy is supplied as standard to fully enclose the barrel mechanism, ensuring the shutter is fully protected for
both internal and external applications alike.
For electric operated shutters, the emergency crank mechanism can be positioned for operation either from inside or from outside.
Cill angles are available for face fixed applications where a window cill is not present.
Standard reveal fix
Mounting the shutter between reveals is common on both doorway and cabinet applications, whereby there is no face present to fix to. Usually the shutter box and guides protrude into the opening.
On wider applications, it is advisable to support the shutter canopy by fixing an angle between the head plate.
Face / Reveal fix
An opening with a face fix arrangement one side and a reveal fix on the other, combines the two typicallayouts as shown above.
LATH
Curtain laths are 44mm deep x 9mm thick, double-skin extruded aluminium, weighing 7kg/m2.
GUIDES
53mm or 66mm extruded guide profiles are available for all shutter sizes. 66mm guides include a profile that holds the lath endlocks captive for higher security.
Sizing
Size range for manual and powered shutters.
Maximum shutter height including box for each endplate size. All sizes in mm.
Technical downloads for Callisto Continental Roller Shutters
Download declaration of performance, safety instructions, fitting instructions and more…
COMPLIANT QUALITY
Quality is central to everything we do – our reputation has been built upon it… Priory was one of the first industrial door manufacturers in the country to test all of its products to what is now known as CPR (Construction Products Regulation) not only for Resistance to Wind Load, but also:
- Forces for Manual Operation
- Safe Opening of Vertical Moving Doors
- Anti-Drop Devices
- Out of Balance Forces
- Operating Forces
- Safety in Use of Power Operated Doors
Your Warranty
Callisto is covered by warranties for the periods stated below, subject to terms and conditions (available on request and supplied with every door) and regular maintenance.
1 YEAR
Warranty on door components against manufacturing defect.
5 YEAR
Warranty on motor and controls excluding batteries and transmitters.
